Product Summary

The BTS4880R is a smart power high-side-switch. It is suitable for output driver for industrial applications (PLC), All types of resistive, inductive and capacitive loads, optocoupler compatible power switch for 24 V DC applications and replaces electromechanical relays and discrete circuits. The applications of the BTS4880R include output driver for industrial applications, all types of resistive, inductive and capacititive loads, μC or optocoupler compatible power switch for 24V DC applications and replaces electromechanical relays and discrete circuits.

Parametrics

BTS4880R absolute maximum ratings: (1)Supply voltage Vbb: -1 to 45 V; (2)Continuous input voltage2) VIN: -10Vbb; (3)Continuous voltage at LS-pin VLS: -1Vbb; (4)Current through input pin (DC), each channel, IIN: ±5 mA; (5)Reverse current through GND-pin), -IGND: 1.6 A; (6)Storage temperature, Tstg: -55 to +150℃; (7)Power dissipation, Ptot: 3.3 W.

Features

BTS4880R features: (1)Output current 0,625 A per channel; (2)Short circuit protection; (3)Maximum current internally limited; (4)Overload protection; (5)Input protection; (6)Overvoltage protection (including load dump); (7)Undervoltage shutdown with auto restart and hysteresis; (8)Switching inductive loads; (9)Thermal shutdown with restart; (10)Thermal independence of separate channels; (11)ESD - Protection; (12)Loss of GND and loss of Vbb protection; (13)Very low standby current; (14)Reverse battery protection; (15)Programmable input for CMOS or Vbb/2; (16)Common diagnostic output ( current output ) for over temperature.
