The TX2-48V is a TX relay.

Parametrics

TX2-48V absolute maximum ratings: (1)Temperature rise: Max. 50℃; (2)Operate time [Set time]:(at 20℃): Max. 4 ms (Approx. 2 ms); (3)Release time [Reset time] (at 20℃): Max. 4 ms (Approx. 1 ms); (4)Shock resistance, Functional: Min. 750 m/s; (5)Destructive: Min. 1,000 m/s2 {100 G}; (6)Vibration resistance, Functional: 196 m/s2 {20 G}, 10 to 55 Hz at double amplitude of 3.3 mm; Destructive: 294 m/s2 {30G}, 10 to 55 Hz at double amplitude of 5 mm; (7)Unit weight: Approx. 2 g.

Features

TX2-48V features: (1)Breakdown voltage between contacts and coil: 2,000 V; (2)Surge withstand between contacts and coil: 2,500 V; (3)High contact capacity: 2 A 30 V DC; (4)Surface-mount type available.
