OP177

OP177, ultraprecision operational amplifier, 22 V, 500 mW, 2.0 mA, CCGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $16.00~18.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	18.00 / Piece
100 ~ 1000 :	16.00 / Piece

PartNumber:: OP177

Brand:: Siemens Semiconductor Group - siemens | Pack: CCGA | D/C: 09+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-19

From Other Seller

Part Number:OP177
US $16.00 - 18.00
Quantity:

piece

Product Summary

The OP177 is an ultraprecision operational amplifier. The OP177 features the highest precision performance of any op amp currently available. Offset voltage of the OP177 is only 10 mV max at room temperature and 20 mV max over the full military temperature range of –55°C to +125°C. The ultralow VOS of the OP177, combines with its exceptional offset voltage drift (TCVOS) of 0.1 mV/°C max, to eliminate the need for external VOS adjustment and increases system accuracy over temperature.

Parametrics

OP177 absolute maximum ratings: (1)Supply voltage: ±22 V; (2)Internal power dissipation: 500 mW; (3)Differential input voltage: ±30 V; (4)Input voltage: ±22 V; (5)Output short-circuit duration: Indefinite; (6)Storage temperature range Z and RC packages: –65°C to +150°C; S, P Package: –65°C to +125°C; (7)Operating temperature range: –55°C to +125°C; (8)Lead temperature range (Soldering, 60 sec): +300°C; (9)DICE junction temperature (TJ): –65°C to +150°C.

Features

OP177 features: (1)Ultralow offset voltage: TA = +258C: 10 mV max; –558C ≤ TA ≤ +1258C: 20 mV max; (2)Outstanding offset voltage drift: 0.1 mV/8C max; (3)Excellent open-loop gain and gain linearity: 12 V/mV typ; (4)CMRR: 130 dB min; (5)PSRR: 120 dB min; (6)Low supply current: 2.0 mA max; (7)Fits industry standard precision op amp sockets.
