Product Summary
The NL6448BC33-64 is a color LCD module. It is composed of the amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film Transistor) array and a backlight.
Parametrics
NL6448BC33-64 absolute maximum ratings:(1)Power supply voltage, LCD panel signal board, VCC: -0.3 to +6.5V (Ta = 25℃); (2)Power supply voltage, Lamp voltage, VBLH: 1,500Vrms; (3)Input voltage for signals, Display signals, VD: -0.3 to VCC+0.3V; (4)Input voltage for signals, Function signals, VF: -0.3 to VCC+0.3V; (5)Storage temperature, Tst: -30 to +80℃; (6)Operating temperature, Front surface, TopF: -20 to +70℃; (7)Operating temperature, Rear surface, TopR: -20 to +70℃; (8)Relative humidity, RH: ≤95 % at the condition of Ta ≤ 40℃; (9)Relative humidity, RH: ≤85 % at the condition of 40 < Ta ≤ 50℃; (10)Relative humidity, RH: ≤55 % at the condition of 50 < Ta ≤ 60℃; (11)Relative humidity, RH: ≤36 % at the condition of 60 < Ta ≤ 70℃; (12)Absolute humidity, AH: < 70 g/m3 at the condition of Ta > 50℃.
Features
NL6448BC33-64 features: (1)wide viewing angle; (2)High luminance; (3)High contrast; (4)6-bit digital RGB signals; (5)DE(Data enable) function; (6)Reversible-scan direction; (7)Edge light type(without inverter); (8)Replaceable lamp for backlight; (9)acquisition products for UL60950-1/CSA NO.60950-1-03.
