MAX642

set-up switching regulator, +18V, 625mA, 800mW, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.70~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	2.00 / Piece
20 ~ 100 :	1.70 / Piece

PartNumber:: MAX642

Brand:: Dallas Semiconductor - Maxim | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-14

From Other Seller

Part Number:MAX642
US $1.70 - 2.00
Quantity:

piece

Product Summary

The max642 is a set-up switching regulator. The max642 is designed for minimum component DC-DC converter circuit in the 5mW to 10W range. Low-power applications of the max642 require only an output filter capacitor and a small, low-cost inductor. The max642 is preset for +5V, +12V, and +15V outptus, respectively. Applications of the max64 include: simple, high-efficiency DC-DC converters, uninterruptible board-level power supplies, power conditioning for battery systems and portable instruments and communications.

Parametrics

max642 absolute maximum ratings: (1) supply voltage VOUT: +18V; (2) output voltage, LX and LBO: +18V; (3) input voltage, LBI, LBI, VFB, COMP: -0.3 to (+VOUT +0.3V) ; (4) LX output current: 450mA peak; (5) LBO ouput current : 50mA; (6) Power dissipation: 625mA (Plastic DIP) , 450mW (Small outline) , 800mW (CERDIP) ; (7) Operating temperature: 0 to +70°C; (8) Storage temperature: -65 to 125°C; (9) Lead temperature (soldering . 10 sec.) : +300°C.

Features

max642 features: (1) fixed +5V, +12V, +15V output voltages; (2) adjustable output with 2 resistors; (3) on-chip driver for high-power external mosfet; (4) 135μA typ operating current; (5) 80% typ efficiency; (6) 8-pin narrow DIp and narrow SO packages.
