L7812CT

L7812CT, negative voltage regulator, CAN, 35V, 1.5A, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.90~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	2.00 / Piece
11 ~ 100 :	1.90 / Piece

PartNumber:: L7812CT

Brand:: STMicroelectronics - ST | Pack: CAN | D/C: 09+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-31

From Other Seller

Part Number:L7812CT
US $1.90 - 2.00
Quantity:

piece

Product Summary

The L7812CT is a negative voltage regulator. The L7812CT is available in TO-220, ISOWATT220 TO-3 and D2PAK packages and several fixed output voltages, making it useful in a wide range of applications.These regulators can provide local on-card regulation, eliminating the distribution problems associated with single point regulation; furthermore, having the same voltage option as the L7800 positive standard series, they are particularly suited for split power supplies. In addition, the -5.2V is also available for ECL system. If adequate heat sinking is provided, they can deliver over 1.5A output current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltages and currents.

Parametrics

L7812CT absolute maximum ratings: (1)DC Input Voltage: 35V; (2)Output Current: Internally limited; (3)Power Dissipation: Internally limited; (4)Operating Junction Temperature Range: 0 to 150 ℃; (5)Storage Temperature Range: - 65 to 150 ℃.
