SMC34C60QFP

PARALLEL PORT INTERFACE CHIP, 7V, 10 seconds, QFP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.40~9.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $8.40~9.00

PartNumber:: SMC34C60QFP

Brand:: SMC Corporation - SMC | Pack: QFP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Pamela's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-27

From Other Seller

Part Number:SMC34C60QFP
US $8.40 - 9.00
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SMC34C60QFP is a parallel port interface chip. In addition to Standard (Compatible) printer ports, the SMC34C60QFP supports PS/2 (bi-directional), EPP, and ECP ports. Up to eight peripherals may be daisy chained between the computer and the printer. Printer operation is unaffected. The SMC34C60QFP also provides a piezo transducer driver for battery-powered systems. The transducer will signal low battery with two repeated beeps. If the cable to the computer is disconnected, or if the host is dormant for about a minute, the transducer will signal inactivity with four beeps. Additionally, a power-down signal can be provided to external circuitry to automatically shut down system power during inactivity.

Parametrics

SMC34C60QFP absolute maximum ratings: (1)Operating Temperature Range: 0℃ to +70℃; (2)Storage Temperature Range: -55℃ to +150℃; (3)Lead Temperature Range (soldering, 10 seconds): +325℃; (4)Positive Voltage on any pin, with respect to Ground: VCC + 0.3V; (5)Negative Voltage on any pin, with respect to Ground: -0.3V; (6)Maximum Vcc: +7V.

Features

SMC34C60QFP features: (1)Creates PC/AT-Style Bus from Parallel Printer Port Signals; (2)Single Chip Interface to Any Bus Capable Peripheral; (3)Supports Standard, Bi-Directional, EPP, and ECP Parallel Ports; (4)Burst Mode for Improved Data Transfer Rates; (5)Adaptive Interface Optimizes Transfer Rates to Parallel Port Characteristics Digital Signal Filtering Increases Noise Immunity; (6)Allows Daisy-Chain of up to Eight Peripherals Including Standard Printer Provides Interrupt Sharing with Daisy-Chained Devices 16-Bit Product ID Support Peripheral Bus Clock Selectable at System Clock 12, 13, 15, or /6 Interfaces to 8-Bit and/or 16-Bit Peripherals.
