S29AL032D70TFI03

S29AL032D70TFI03, 32 Megabit CMOS Flash Memory, TSOP, -0.5 V to +12.5 V, 200mA, SPANSION

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.70~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	2.00 / Piece
20 ~ 100 :	1.70 / Piece

PartNumber:: S29AL032D70TFI03

Brand:: SPANSION - spansion | Pack: TSOP | D/C: 09+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-28

From Other Seller

Part Number:S29AL032D70TFI03
US $1.70 - 2.00
Quantity:

piece

Product Summary

The S29AL032D70TFI03 is a 32 megabit, 3.0 volt-only flash memory device, organized as 2,097,152 words of 16 bits each or 4,194,304 bytes of 8 bits each. Word mode data appears on DQ0-DQ15; byte mode data appears on DQ0-DQ7. The S29AL032D70TFI03 is designed to be programmed in-system with the standard 3.0 volt VCC supply, and can also be programmed in standard EPROM programmers.

Parametrics

S29AL032D70TFI03 absolute maximum ratings: (1)Storage Temperature Plastic Packages: -65℃ to +150℃; (2)Ambient Temperature with Power Applied: -65℃ to +125℃; (3)Voltage with Respect to Ground; (4)All pins except A9 and OE#: -0.5 V to VCC+0.5 V; VCC: -0.5 V to +4.0 V; A9 and OE#: -0.5 V to +12.5 V; (5)Output Short Circuit Current: 200 mA.

Features

S29AL032D70TFI03 features: (1)Single power supply operation, Full voltage range: 2.7 to 3.6 volt read and write operations for battery-powered applications; (2)Manufactured on 200 nm process technology, Fully compatible with 0.23 μm Am29LV320D, 0.32 μm Am29LV033C, and 0.33 μm MBM29LV320E devices; (3)Flexible sector architecture, Boot sector models: Eight 8-Kbyte sectors; sixtythree 64-Kbyte sectors; top or bottom boot block; (4)configurations available; Uniform sector models: Sixty-four 64-Kbyte sectors; (5)Sector Protection features, A hardware method of locking a sector to prevent any program or erase operations within that sector; Sectors can be locked in-system or via programming; (6)equipment; Temporary Sector Unprotect feature allows code; (7)changes in previously locked sectors; (8)Unlock Bypass Program Command, Reduces overall programming time when issuing multiple program command sequences.
