QM20TD-HB

QM20TD-HB, MITSUBISHI TRANSISTOR MODULE, 600V, 20A , 83W, OBGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.00~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 5 :	10.00 / Piece
6 ~ 20 :	9.00 / Piece

PartNumber:: QM20TD-HB

Brand:: MITSUBISHI Electronics - MITSUBISHI | Pack: OBGA | D/C: 07+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-14

From Other Seller

Part Number:QM20TD-HB
US $9.00 - 10.00
QM20TD-HB Trans IGBT Module N-CH 600V 20A

US $8.60 - 12.50 / Piece
(0) Remove
QM20TD-HB

US $50.00 - 50.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The QM20TD-HB is a MITSUBISHI TRANSISTOR MODULE. The applications of the QM20TD-HB are Inverters, Servo drives, DC motor controllers, NC equipment, Welders.

Parametrics

QM20TD-HB absolute maximum ratings: (1)Collector-emitter voltage VCEX (IC=1A, VEB=2V): 600V; (2)Collector-base voltage VCBO: 600V; (3)Emitter-base voltage VEBO: 7V; (4)Collector current IC: 20A; (5)Collector dissipation PC(Tc=25): 83W; (6)Base current IB: 1A; (7)Surge collector reverse current(forward diode current) ICSM: 200A; (8)Junction temperature Tj: -40℃ to +150℃; (9)Storage temperature TSTG: -40℃ to +125℃; (10)Isolation voltage Viso: 2500V.

Features

QM20TD-HB features: (1)IC Collector current: 20A; (2)VCEX Collector-emitter voltage: 600V; (3)hFE DC current gain: 250; (4)Insulated Type; (5)UL Recognized.
