ADG419BR

monolithic CMOS SPDT switch, SOP8, –0.3 V to VDD + 0.3 V, Low On Resistance, 30 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~10.00

PartNumber:: ADG419BR

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Pamela's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-23

From Other Seller

Part Number:ADG419BR
US $1.00 - 10.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
LM285M-2.5

US $0.16 - 0.25 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADG419BR is a monolithic CMOS SPDT switch. This switch is designed on an enhanced LC2 MOS process that provides low power dissipation yet gives high switching speed, low on resistance and low leakage currents. The applications of the device include Precision Test Equipment, Precision Instrumentation, Battery Powered Systems and Sample Hold Systems.

Parametrics

ADG419BR absolute maximum ratings: (1)VDD to VSS: +44 V; (2)VDD to GND: –0.3 V to +25 V; (3)VSS to GND: +0.3 V to –25 V; (4)VL to GND: –0.3 V to VDD + 0.3 V; (5)Analog, Digital Inputs: VSS – 2 V to VDD + 2 V or 30mA, Whichever Occurs First; (6)Continuous Current, S or D: 30 mA; (7)Peak Current, S or D:100 mA; (8)Operating Temperature Range: –40℃ to +85℃; (9)Storage Temperature Range: –65℃ to +150℃; (10)Junction Temperature: +150℃; (11)Cerdip Package, Power Dissipation: 600 mW; (12)θJA, Thermal Impedance: 110℃/W; (13)Lead Temperature, Soldering (10 sec): +300℃; (14)Plastic Package, Power Dissipation: 400 mW; (15)θJA, Thermal Impedance: 100℃/W; (16)Lead Temperature, Soldering (10 sec): +260℃; (17)SOIC Package, Power Dissipation: 400 mW; (18)θJA, Thermal Impedance: 155℃/W; (19)μSOIC Package, Power Dissipation: 315 mW; (20)θJA, Thermal Impedance: 205℃/W; (21)Lead Temperature, Soldering, Vapor Phase (60 sec): +215℃; Infrared (15 sec): +220℃.

Features

ADG419BR features: (1)44 V Supply Maximum Ratings; (2)VSS to VDD Analog Signal Range; (3)Low On Resistance (< 35 V); (4)Ultralow Power Dissipation (< 35 mW); (5)Fast Transition Time (160 ns max); (6)Break-Before-Make Switching Action; (7)Plug-In Replacement for DG419.
