Product Summary

The max206eeag is a ±15kV ESD-Protected, +5V RS-232 transceiver. The max206eeag is designed for RS-232 and V.28 communications in harsh environments. Applications of the max206eeag include: Notebook, Subnotebook, and Palmtop Computers, Battery-Powered Equipment and Hand-Held Equipment.

Parametrics

max206eeag absolute maximum ratings: (1) VCC:-0.3 to +6V; (2) V+: (VCC -0.3V) to +14V; (3) V-: -14 to +0.3V; (4) Input Voltages T_IN: -0.3 to (V+ +0.3V), R_IN: ±30V; (5) Short-Circuit Duration, T_OUT: Continuous; (6) Storage Temperature Range: -65 to +165°C; (7) Lead Temperature (soldering, 10sec) : +300°C; (8) Operating Temperature Ranges: -40 to +85°C.

Features

max206eeag features: (1) For Low-Voltage Applications; (2) For Low-Power Applications; (3) For Space-Constrained Applications; (4) For Low-Voltage or Data Cable Applications.

Diagrams

max206eeag pin configuration
