Product Summary
The M61537FP is a 6ch electronic volume. The M61537FP is controlled by 2-wire serial bus and is suitable for Home Audio System. Applications of the M61537FP are Receiver, AV Amp, Mini Stereo etc..
Parametrics
M61537FP absolute maximum ratings: (1)Maximum Supply voltage VDD max VDD1, VDD2, VDD3, VDD4 VDD1=VDD2=VDD3=VDD4: -0.3 to +6.5V; (2)Input voltage VI(1)XT1, CF1: -0.3 to VDD+0.3V; (3)Input/Output Voltage VIO(1)Ports 0, 1, 2 Ports 3, 7, 8 Ports A, B, C, E, F SI2P0 to SI2P3 PWM0, PWM1,XT2: -0.3 to VDD+0.3 V; (4)Peak output current: 30mA; (5)Average output current: 20mA; (6)Total output current: 80mA; (7)Maximum power dissipation Pd max QIP100E(14×20)Ta=-40 to +85℃: 320 mW; (8)Operating ambient temperature Topr: -40 to +85℃; (9)Storage ambient temperature Tstg: -55 to +125 ℃.
Features
M61537FP features: (1)Analog Power supply VCC-VEE: 16 V; (2)Digital Power supply DVDD-DGND: 7 V; (3)Power dissipation Pd Ta ≤ 25℃: 1.0 W; (4)Thermal derating K Ta > 25℃: 10.0 mW/℃; (5)Operating temperature Topr: –20 to +75 ℃; (6)Storage temperature Tstg: -40 to +125 ℃.
