Product Summary
The KSS-213C is a subminiature Side Actuated Tact Switch for SMT. Applications include Cellular phone, PDA, pagers, Industrial electronics and Health diagnostic electronics.
Parametrics
KSS-213C absolute maximum ratings: (1)maximum power: 1VA(Silver) 0.2VA(Gold); (2)maximum voltage: 50VDC(Silver) 50VDC(Gold); (3)maximum current: 50 mA(Silver) 10mA(Gold); (4)minimum current: 1 mA(Silver) 1mA(Gold); (5)ielectric strength: ≥ 250VDC; (6)contact resistance: ≤ 100 mΩ; (7)insulation resistance (100VDC): ≥ 109Ω; (8)bounce time: ≤ 3 ms.
Features
KSS-213C features: (1)Low profile of 1.6 mm; (2)Excellent tactile feel; (3)High shear force; (4)Range of actuation forces; (5)Large flat top; (6)Redundant contacts option; (7)Date code marking.
Diagrams
