HN29V51211T-50H

HN29V51211T-50H, CMOS Flash Memory, 4.6 V, 40 mA, 1.0 ms, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	2.00 / Piece
20 ~ 100 :	1.80 / Piece

PartNumber:: HN29V51211T-50H

Brand:: Hitachi Ltd - Hitachi | Pack: TSOP | D/C: 09+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-02

From Other Seller

Part Number:HN29V51211T-50H
US $1.80 - 2.00
Quantity:

piece

Product Summary

The HN29V51211T-50H is a CMOS Flash Memory with AND type multi-level memory cells. The HN29V51211T-50H has fully automatic programming and erase capabilities with a single 3.0 V power supply. The functions are controlled by simple external commands. To fit the I/O card applications, the unit of programming and erase is as small as (2048 + 64) bytes. Initial available sectors of the HN29V51211T-50H are more than 32,113 (98% of all sector address) and less than 32,768 sectors.

Parametrics

HN29V51211T-50H absolute maximum ratings: (1)VCC voltage VCC: -0.6 to +4.6 V; (2)All input and output voltages Vin, Vout: -0.6 to +4.6 V; (3)Operating temperature range Topr: 0 to +70 °C; (4)Storage temperature range Tstg: -65 to +125 °C; (5)Storage temperature under bias Tbias: -10 to +80 °C; (6)Operating VCC current (Program)ICC3: 20 to 40 mA; (7)Operating VCC current (Erase)ICC4: 20 to 40 mA; (8)Input leakage current ILI: 2 μA Vin = VSS to VCC; (9)Output leakage current ILO: 2 μA Vout = VSS to VCC.

Features

HN29V51211T-50H features: (1)Sector program time: 1.0 ms (typ); (2)System bus free; (3)Address, data latch function; (4)Internal automatic program verify function; (5)Status data polling function; (6)On-board single power supply (VCC): VCC = 2.7 V to 3.6 V; (7)Error correction: more than 3-bit error correction per each sector read; (8)Spare sectors: 1.8% (579 sectors)within usable sectors.
