AD532JHZ

Internally Trimmed Integrated Circuit Multiplier, ±10V, 10Ω, ±25 μA, CAN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.70~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	2.00 / Piece
20 ~ 100 :	1.70 / Piece

PartNumber:: AD532JHZ

Brand:: Analog Devices - ADI | Pack: CAN | D/C: 07+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-18

From Other Seller

Part Number:AD532JHZ
US $1.70 - 2.00
Quantity:

piece

Product Summary

The AD532JHZ is an internally trimmed integrated circuit multiplier. The AD532JHZ is the first pretrimmed single chip monolithic multiplier/ divider. It guarantees a maximum multiplying error of ±1.0% and a ±10 V output voltage without the need for any external trimming resistors or output op amp. Because the AD532JHZ is internally trimmed, its simplicity of use provides design engineers with an attractive alternative to modular multipliers, and its monolithic construction provides significant advantages in size, reliability and economy. Further, the AD532JHZ can be used as a direct replacement for other IC multipliers that require external trim networks. The applications of the AD532JHZ include Multiplication, Division, Squaring, Square Rooting, Algebraic Computation, Power Measurements, Instrumentation Applications, Available in Chip Form.

Parametrics

AD532JHZ absolute maximum ratings: (1)Output Voltage Swing: ±10 to ±13 V; (2)Output Impedance (f ≤ 1 kHz): 1 Ω; (3)Output Offset Voltage: ±30 mV; (4)Output Offset Voltage vs. Temperature: 2.0 mV/℃; (5)Output Offset Voltage vs. Supply: ±2.5 mV/%; (6)Signal Voltage Range (Diff. or CM Operating Diff): ±10 V; (7)CMRR: 50 dB; (8)Input Bias Current, X, Y Inputs 1.5 to 4 μA; X, Y Inputs TMIN to TMAX: 8 μA; Z Input: ±5 to ±15 μA; Z Input TMIN to TMAX: ±25 μA; (9)Offset Current: ±0.1 μA; (10)Differential Resistance: 10Ω.

Features

AD532JHZ features: (1)Pretrimmed to 61.0%; (2)No External Components Required; (3)Guaranteed 61.0% max 4-Quadrant Error; (4)Diff Inputs for (X1 – X2) (Y1 – Y2)/10 V Transfer Function; (5)Monolithic Construction, Low Cost.
