TL074CN

TL074CN, high-speed JFET input single operational amplifier, DIP-14, ±18 V, 680mW, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	1.20 / Piece
11 ~ 100 :	1.00 / Piece

PartNumber:: TL074CN

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-05

From Other Seller

Part Number:TL074CN
US $1.00 - 1.20
TL074CNSR

US $0.22 - 0.22 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TL074CN is a high-speed JFET input single operational amplifier. The JFET input operational amplifier incorporates well matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The TL074CN features high slew rates, low input bias and offset currents, and low offset voltage temperature coefficient.

Parametrics

TL074CN absolute maximum ratings: (1)Supply voltage: ±18 V; (2)Vi Input voltage: ±15 V; (3)Vid Differential input voltage: ±30 V; (4)Ptot Power dissipation: 680 mW; (5)Rthja, Thermal resistance junction to ambient, DIP14: 80℃/W; SO-14: 105℃/W; (6)Thermal resistance junction to case, DIP14: 33; SO-14: 31℃/W; (7)Output short-circuit duration: Infinite; (8)Toper Operating free-air temperature range: -40 to +105℃; (9)Tstg Storage temperature range: -65 to +150 ℃; (10)ESD, HBM: human body model(7): 1 kV; MM: machine model(8): 200 V; CDM: charged device model(9): 1.5 kV.

Features

TL074CN features: (1)Wide common-mode (up to VCC+) and differential voltage range; (2)Low input bias and offset current; (3)Low noise en = 15 nV/ √Hz (typ); (4)Output short-circuit protection; (5)High input impedance JFET input stage; (6)Low harmonic distortion: 0.01% (typical); (7)Internal frequency compensation; (8)Latch up free operation; (9)High slew rate: 16 V/μs (typical).
