Product Summary

The SH2003C is an NPN epitaxial silicon transistor.

Parametrics

APT8011JFLL absolute maximum ratings: (1)Collector-base voltage: 40 V; (2)Collector-emitter voltage: 25 V; (3)Emitter-base voltage: 8 V; (4)Base current: 1 A; (5)Collector current (DC): 5 A; (6)Collector current (Pulse): 10 A; (7)Collector dissipation (TC = 25°C): 12.5 W; (8)Collector dissipation (Ta = 25°C): 1.4 W; (9)Junction temperature: 150 °C; (10)Storage temperature: - 55 ~ 150 °C.

Features

APT8011JFLL features: (1)High DC current gain; (2)Built-in a damper diode at E-C; (3)Lead Formed for surface mount applications (No suffix); (4)Straight lead (I-PAK, “ - I “ suffix).

Diagrams

APT8011JFLL pin connection
