OP15

OP15, input operational amplifier, 22 V, 6 MHz, 80 mW, CCGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $16.00~17.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	17.00 / Piece
20 ~ 100 :	16.00 / Piece

PartNumber:: OP15

Brand:: Siemens Semiconductor Group - siemens | Pack: CCGA | D/C: 09+

Availability:: Supply Ability: 1/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Pamela's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-19

From Other Seller

Part Number:OP15
US $16.00 - 17.00
Quantity:

piece

Product Summary

The OP15 is an input operational amplifier. The OP15 provides an excellent combinations of high speed and low input offset voltage. In addition, the OP15 offers the speed of the 156A op amp with the power dissipation of a 155A. The combination of a low input offset voltage of 500 mV, slew rate of 13 V/ms, and settling time of 1,200 ns to 0.1% makes the OP15 an op amp of both precision and speed. The additional features of low supply current coupled with an input bias current makes the OP15 ideal for a wide range of applications.

Parametrics

OP15 absolute maximum ratings: (1)Supply voltage all devices except C, G (packaged)and GR grades: ±22 V; C, G (packaged)and GR grades: ±18 V; (2)Operating temperature A grade: –55 to +125℃; E, F grades: 0℃ to 70℃; G grade: –40℃ to +85℃; (3)Maximum junction temperature: 150℃; (4)Differential input voltage all devices except C, G grades: ±40 V; C, G grades: ±30 V; (5)Input voltage2 all devices except C, G grades: ±20 V; C, G grades: ±16 V; (6)Input voltage OP15E, OP15F: ±20 V; OP15G: ±16 V; OP17A, OP17E, OP17F: ±20 V; OP17G: ±16 V; (7)Output short-circuit duration indefinite storage temperature range: –65℃ to +150℃; (8)Lead temperature range (soldering, 60 sec): 300℃.

Features

OP15 features: (1)Significant performance advantages over LF155 and LF157 devices; (2)Low input offset voltages: 500 μV Max; (3)Low input offset voltage drift: 2.0 μV/℃; (4)Minimum slew rate guaranteed on all models; (5)Temperature-compensated input bias currents; (6)Bias current specified warmed-up over temperature; (7)Internal compensation; (8)High common-mode rejection ratio: 100 dB; (9)Models with MIL-STD 883 processing available; (10)156 speed with 155 dissipation: 80 mW typ; (11)Wide bandwidth: 6 MHz; (12)High slew rate: 13 V/μs; (13)Fast settling to ±0.1%: 1,200 ns.
