Product Summary
The LH28FI60BJE-TTL90 16 M-bit (1 MB x 16) Smart 3 Flash Memory is a high-density, low-cost, nonvolatile, read/write storage solution for a wide range of applications. The LH28FI60BJE-TTL90 can operate at VCC and VPP = 2.7 V. The low voltage operation capability realizes longer battery life and suits for cellular phone application. The boot, parameter and main-blocked architecture, flexible voltage and enhanced cycling capability provide for highly flexible component suitable for portable terminals and personal computers. The enhanced suspend capabilities of the LH28FI60BJE-TTL90 provide for an ideal solution for code + data storage applications.
Parametrics
LH28FI60BJE-TTL90 absolute maximum ratings: (1)Storage Temperature: –65 to +125℃; (2)Voltage On Any Pin (except VCC, VPP, and RP#): –0.5 V to VCC+0.5 V; (3)VCC Supply Voltage: –0.2 to +3.9 V; (4)VPP Update Voltage during Block Erase and Word Write: –0.2 to +14.0 V; (5)RP# Voltage: –0.5 to +14.0 V; (6)Output Short Circuit Current: 100 mA.
Features
LH28FI60BJE-TTL90 features: (1)Smart 3 technology; (2)High performance read access time; (3)Enhanced automated suspend options; (4)SRAM-compatible write interface; (5)Optimized array blocking architecture; (6)Enhanced cycling capability: 100 000 block erase cycles; (7)Low power management; (8)Automated word write and block erase; (9)ETOXTM V nonvolatile flash technology.
Diagrams
