Product Summary
The DSEI30-12A is a Fast Recovery Epitaxial Diode. The applications of the DSEI30-12A include Antiparallel diode for high frequency switching devices, Anti saturation diode, Snubber diode, Freewheeling diode in converters and motor control circuits, Rectifiers in switch mode power supplies (SMPS), Inductive heating and melting, Uninterruptible power supplies (UPS) and Ultrasonic cleaners and welders.
Parametrics
DSEI30-12A absolute maximum ratings: (1)IFRMS : 70 A; (2)IFAVM : 26 A; (3)IFRM : 375 A; (4)IFSM : 200 A; (5)I2t : 200 A2s; (6)TVJ : -40...+150 ℃; (7)TVJM : 150 ℃; (8)Tstg : -40 to +150 ℃; (9)Weight : 6 g.
Features
DSEI30-12A features: (1)International standard package JEDEC TO-247 AD; (2)Planar passivated chips; (3)Very short recovery time; (4)Extremely low switching losses; (5)Low IRM-values; (6)Soft recovery behaviour; (7)Epoxy meet UL 94V-0.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DSEI30-12A |
Ixys |
Rectifiers 1200V 26A |
Data Sheet |
Negotiable |
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
 |
DSEI 2x101 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
 |
DSEI 2X61-02A |
|
DIODE FRED 200V 71A SOT-227 |
Data Sheet |
|
|
||||||
|
DSEI12 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
DSEI120 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
 |
DSEI120-06A |
Ixys |
Rectifiers 120 Amps 600V |
Data Sheet |
Negotiable |
|
||||||
|
DSEI120-12A |
Ixys |
Rectifiers 120 Amps 1200V |
Data Sheet |
Negotiable |
|
||||||
