Product Summary
The 4082IBZ is a CMOS and gate, provides the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates. The 4082IBZ is supplied in 14-lead hermetic dual-in-line ceramic packages (F3A suffix), 14-lead dual-in-line plastic packages (E suffix), 14-lead small-outline packages (M, MT, M96, and NSR suffixes), and 14-lead thin shrink small-outline packages (PW and PWR suffixes).
Parametrics
4082IBZ absolute maximum ratings: (1)DC SUPPLY-voltage(Vdd) Voltages referferenced to Vss Terminal): -0.5V to +20V; (2)Input voltage range, all inputs: -0.5V to VDD +0.5V; (3)DC inpot curftent, any oneinput: ±10mA: 500mW; For Ta=100℃ to +125℃: Derate LirwarHy at 12mW/℃ to 200mW; (4)device dissipation per output transistor, FOR TA= FULL package-temperature range (All Package Types): l00mW; (5)Operating-temperature range (TA): -55℃ to +125℃; (6)STORAGE TEMPERATURE RANGE (Tstg): -65℃ to +150℃; (7)Lead temperature (during soldering): At distance 1/16 ± 1 /32 inch (1.59 ± 0,79mm) from for 10s max: +265℃.
Features
4082IBZ features: (1)Medium-Speed Operation — tpLH, tpHL = 60 ns (typ.) at VDD = 10V ; (2)100% tufted lor quiescent current at 20 V; (3)Maximum input current of 1 fiA at 18 V over full package-temperature range; 100 nA at 18 V and 25℃Noise margin (full package-temperature range)- 1V at VDD = 5 V; 2V at VDD= 10 V; 2.5 V at VDD = 15 V; (4)Standardjzed, symmetrical output, characteristics; (5)5-V,10-V, and 15-V parametric ratings; (6)Mteti aH requirements of JEDEC Tentative StarMtard No, 13D, "Standard Specifications for Description of "B" Series CMOS Devices".
Diagrams
 |
