Product Summary

The 2SC503X is a silicon NPN epitaxial type PCT process. It is suitable for high frequency amplifier applicaitons and high speed switching applications.

Parametrics

2SC503X absolute maximum ratings: (1)collector-base voltage, VCBO: 100V; (2)collector-emitter voltage, VCEO: 80V; (3)emitter-base votlage, VEBO: 5V; (4)collector current, IC: 600mA; (5)base current, IB: 100mA; (6)collector power dissipation, PC: 800W; (7)junction temperature, Tj: 175℃; (8)storage temperature range, Tstg: -65 to 175℃.

Features

2SC503X features: (1)high transistion frequency: fT=80MHz typ; (2)high breakdown votlage: VCEO=80V; (3)complementary to 2SA503 and 2SA504.

Diagrams

2SC503X dimensions
